The Finlay 863+ mobile screening plant is a compact and aggressive forward facing screen. This flexible and mobile plant can work in aggregates, sand and gravel, top soil, construction demolition and recycling applications where site space is at a premium. The fully self contained plant can be hydraulically folded and ready for transport in less than an hour making it the ideal machine for contract screening. The plant has the capacity to process at a rate of up to 280 tonnes per hour and can be fed either by a tracked mobile crusher or an excavator. Features: • Hopper and feeder: Hopper Capacity: 5m³ (6.54yd³) with hydraulic folding hopper extensions; Feed height: 3.3m (10' 10"); Feed in width: 2.2m (7' 3"); Drive: Hydraulic variable speed • Screenbox: Top deck: 2.76m x 1.22m (9' x 4'); Bottom deck: 2.76m x 1.22m (9' x 4'); Screen Angle: 14°, 18°, hydraulic adjust; Screen box discharge end raises hydraulically 500mm to facilitate mesh changing; Total screening area: 6.7m² (72ft2) • Midgrade Conveyor • Oversize plus conveyor: Belt width: 1m (40"); Working Angle: 15°, 24°, hydraulic adjust; Discharge Height: 3.5m (11' 6"); Stockpile capacity: 64m3 (83.8yd3) max • Undercarriage: Shoe Width: 400mm (16"); Dual speed tracking; Gradeability: 39°; Raking Angle: 9° min • Fines conveyor: Belt width: 650mm (26"); Working Angle: 25°; Standard Discharge Height: 3.85m (12' 8"); Stockpile capacity: 85m3 (111yd3) Specifications: • Screen: 9' x 4' (2.76m x 1.22m) • Transport Length: 31 ft 6 in (9 m 60 cm) • Working Dimensions: Height 12' 8", Width 46' 93', Length 39' 8" (Height 3.85m, Width 14.1m, Length 12.1m) • Transport Width: 8 ft 4 in (2 m 55 cm) • Weight: 40,350 lbs with options (18,300 kg with options) • Transport Height: 10 ft 2 in (3 m 10 cm) • Net Engine Power: Tier 4F / Stage V: Caterpillar C2.2 74 hp Dual Certified (Caterpillar C2.2 55 kW Dual Certified) • Net Engine Power: Tier 3: CAT C4.4 82 hp (CAT C4.4 64 kW) • Output Potential: 309 US tph (280 tph)
