Remote tipping reject grid, hydraulic screen tensioning of bottom deck mesh and three on board hydraulic folding conveyors are standard. Features: • Oversize & Mid grade conveyors: Belt width: 650mm (26"); Working Angle: 24°; Hydraulic Folding; Discharge Height: 4.72m (14'); Stockpile capacity: 194m³ (254yd³) Specifications: • Transport Length: 49 ft 3 in (15 m) • Transport Height: 10 ft 8 in (3 m 25 cm) • Screen: 12' x 5' (3.7m x 1.5m) • Transport Width: 9 ft 10 in (3 m) • Weight: 53,462 lbs with options (24,250 kg with options) • Working Dimensions: Height 17' 5", Width 56' 7", Length 54' 0" (Height 5.3m, Width 17.25m, Length 16.5m) • Net Engine Power: Tier 3 / Stage IIIA: T3 CAT C4.4 111 hp or T3 CAT C4.4 130 hp (T3 CAT C4.4 83 kW or T3 CAT C4.4 97 kW) • Net Engine Power: Tier 4 Final / Stage V: CAT C3.6 110 hp Dual certified (CAT C3.6 82 kW Dual certified) • Output Potential: 441 US tph (400 tph)
