The Finlay TC100 stockpiling conveyor has been engineered to work in a range of applications, from screening light and fines materials to primary crushing applications. The machine has been built to optimise the efficiency of site operations and maximise stockpile capacity while reducing or eliminating the use of wheeled loaders or auxiliary equipment on site. Features: • Feedboot: Capacity: 0.6 m3 (0.8yd3); Feed height: 1.8m; Feed in width: 1.30m • Conveyor: Length: 30m (98' 9"); Belt width: 1050mm (42") • Stockpile capacity: Maximum conical stockpile capacity based on 37° angle of repose: 6632 tonnes (7310 US ton). • Hybrid technology: The machine is available with hybrid technology consisting of on board electrical motors permitting the flexibility to run the plant from an outside power supply or standard on board engine. Specifications: • Net Engine Power: Tier 3 / Stage IIIA: CATC4.4 111 hp (CATC4.4 83 KW) • Net Engine Power: Tier 4F / Stage V: CAT C 2.2 74 hp Dual certified (CAT C 2.2 55 kW Dual certified) • Belt Width: 42 in (1,050 mm) • Max Discharge Height: 43 ft 11 in (13.1 m) • Transport Width: 9 ft 4 in (2 m 84 cm) • Transport Height: 9 ft 9 in (3 m) • Transport Length: 63 ft 11 in (19 m 50 cm) • Conveyor Length: 98 ft 9 in (30 m) • Output Potential: 661 US tph (600 tph)
